Features
Four tool magazines with automatic tool changing
The straight-line four-tool magazine allows for continuous and efficient processing, which can be used to make horn handles, embedded handles, laminos, and a variety of invisible parts.
21-inch color screen control display
Adopt 21-inch color screen control display,
Single-arm suspension is easy to operate and saves space.
Safe and reliable operation, simple and friendly interface,
Comes with complete operating tips and troubleshooting guidelines
Double gripper
Using C-shaped groove double clamping mechanism, according to the computer drilling program,
Automatically control board feeding and positioning to improve drilling accuracy.
The clamping hand will lift up and hang in the air when the clamping plate moves. The plate should be kept at a certain distance above the processing table to avoid damage to the plate surface due to collision between the plate and the table.
*Optional four-clamp handle
Taiwan Syntec Motor
Servo controlled gripper positioning quickly and accurately
The gripper speed can reach up to 130m/min
Flexible discharging
Optional front/rear/side discharging
Combined with the automatic lifting and unloading table, multiple unloading options are convenient
Automated wiring
Frog leaping technology
Parabolic trajectory reduces idling time and enables fast drilling speed.
Improve efficiency
Rack and pinion
The rack and pinion is used to transmit the motion power between any two axes and can ensure constant transmission.
Precision guide rail
The extended running guide rail has no limit on the length of the plate to be processed. One-time positioning reduces the number of clamp changes of the clamping hand and increases the processing speed of the plate.
Automatic oil filling system
Electric oiling system, all tracks use electric oil supply, ensuring uniform oiling of all tracks every time.
Independently developed HHM software
Split the order system, optimize the system,
Important aspects of production such as order tracking and packaging systems are connected in series in one software system.
Achieve universal data synchronization,
Reduce error rate and reduce operation steps.
Taiwan Syntec Control System
Adopting Windows human-machine interface and Taiwan’s new generation control system,
Drilling data can be imported using CAD, which is quick and convenient to operate.
Can be matched with user production design management software, no need to input drilling data independently.
Scan the QR code for quick processing, automatically load processing graphics files and generate processing programs.
